EINHELL TC-SS 405 E Instruction Manual

Contents [ hide
1 Einhell Fretsaw
2 Safety regulations
3 Layout and items supplied
3.1 Layout (Fig. 1-4)
4 Items supplied
5 Technical data
6 Before starting the equipment
6.1 General information
6.2 Assembly
7 Operation
7.1 Please note:
7.2 On/Off switch (Fig. 3)
7.3 Blade speed regulator (Fig. 3)
7.4 Carrying out internal cuts
8 Cleaning, maintenance and ordering of spare
parts
8.1 Cleaning
8.2 Carbon brushes
8.3 Maintenance
8.4 Ordering replacement parts:
9 Disposal and recycling
10 Storage
11 Service information
12 Warranty certificate
13 File Downloads
14 References
15 Related Manuals
Einhell Fretsaw

EINHELL TC-SS 405 E Specifications

General

Maximum power	120 W
AC input voltage	230 V
AC input frequency	50 Hz
Blade length	127 mm
Throat depth	406 mm
Product color	Black, Grey, Red
Stroke height	14 mm
Idle speed (max)	1600 RPM
Idle speed (min)	400 RPM
Cutting height @ 45°	20 mm
Cutting height @ 90°	52 mm

Weight and Dimensions

Weight	12500 g
Table depth	250 mm
Table width	408 mm
Package depth	644 mm
Package width	316 mm
Package height	330 mm
Package weight	13450 g
