6. Operation
6.1 ON/OFF switch (Fig. 1/Item 1)
To switch on:
Press the ON/OFF switch
To switch off :
Release the ON/OFF switch
6.2 Locking button (Fig. 1/Item 2)
You can lock the ON/OFF switch (1) using the lo-
cking button (2) when the equipment is in operati-
on. To switch off the equipment briefl y hold down
the ON/OFF switch (1).
6.3 Function switch (Fig. 4-6/Item 7)
Important. Activate the function switch (7)
only when the equipment is at a standstill.
You can move the soleplate (5) to 4 diff erent set-
tings to work better in hard-to-reach areas.
To move the soleplate (5), set the function switch
(7) to position A (see Figure 4).
To lock the soleplate (5) in place, set the function
switch (7) to position B (see Figure 5). The sole-
plate (5) can be locked in only four positions (at
90°, 180°, 270° and 360°). Now check that the
soleplate (5) is secure by turning it.
The pendulum action is activated in position C
(see Figure 6). The saw balde will then move
forwards and backwards in addition to its up and
down movements. This will improve the sawing
performance through better chip discharge. In this
position the soleplate (5) is always locked.
Important. To switch the function switch (7) to
position C, the soleplate (5) must be set to 180°
or 360°.
6.4 Use as a jigsaw (Fig. 7)
Place the multi-saw on the material to be cut as
shown in Fig. 7. Switch on the multi-saw and push
it along against the material to be cut. Adapt your
cutting speed to the material.
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Danger! The carbon brushes should not be rep
laced by anyone but a qualifi ed electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
8.4 Ordering spare parts and accessories
Please provide the following information when
ordering spare parts:
•
Type of unit
•
Article number of the unit
•
ID number of the unit
•
Spare part number of the required spare part
For our latest prices and information please go to
www.isc-gmbh.info
