GB
- 16 -
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
Check the drilling point for concealed electrical
cables, gas and water pipes using a cable/pipe
detector.
5.1 Additional handle (Fig. 2 – Item 3)
For safety reasons you must only use the
hammer drill with the additional handle.
The additional handle (3) enables you to achieve
better stability whilst using the hammer drill. The
machine must not be used without the additional
handle (3) for safety reasons.
The additional handle (3) is secured to the
hammer drill by a clamp. Turning the handle anti-
clockwise (looking from the handle) will release
the clamp. Turning the handle clockwise will tigh-
ten the clamp.
First release the additional handle clamp. You can
then swing the additional handle (3) into the most
comfortable working position for you. Now turn
the additional handle in the opposite direction
again until the additional handle is secure.
5.2 Tool insertion (Fig. 4)
•
Clean the tool before insertion and apply a
thin coating of drill bit grease to the shaft of
the tool.
•
Pull back and hold the locking sleeve (2).
•
Insert the dust-free tool into the tool mounting
as far as it will go whilst turning it. The tool will
lock itself.
•
Check that it is properly secure by pulling the
tool.
5.3 Tool removal (Fig. 5)
Pull back and hold the locking sleeve (2) and re-
move the tool.
6. Operation
Danger!
To avoid danger, the machine is allowed to be
held only by the two handles (3/7)! Otherwise
you may suer an electric shock if you drill into
electric cables!
6.1 Switching On and O (Fig. 5)
Switching on:
Press the On/O switch (6)
Continuous operation:
Secure the On/O switch (6) with the On/O
switch lock (5).
Switching o:
Press the On/O switch (6) briey or let it go.
6.2 Speed control (Fig. 5/Item 8)
The machine is equipped with electronic speed
control. You can preselect the speed by turning
the speed controller (8):
Plus direction: Higher speed
Minus direction: Lower speed
6.3 Selector switch for impact drilling / chis-
eling (Fig. 6)
•
For hammer drilling, press the button (E) on
the rotary switch (4) and simultaneously turn
the rotary switch (4) to position A.
•
For chiseling, press the button (E) on the rota-
ry switch (4) and simultaneously turn the rota-
ry switch (4) to position B. In switch position B
the chisel is not locked.
•
For chiseling, press the button (E) on the
rotary switch (4) and simultaneously turn the
rotary switch (4) to position C. The chisel is
locked in position C.
Important.
Only low pressure is required for hammer drilling.
Excessive pressure will exert an unnecessary
force on the motor. Check the drill bits at regular
intervals. Sharpen or replace blunt drill bits.
Anl_TE_RH_40_3F_SPK13.indb 16 17.05.2021 15:22:37
