EINHELL TH-MS 2112 Original Operating Instructions

GB
- 19 -
 Important!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
 Caution!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
2. Layout and items supplied
2.1 Layout (Fig. 1/2)
1. Release lever
2. Handle
3. ON/OFF switch
4. Machine head
5. Saw blade
6. Movable blade guard
7. Stop rail
8. Turntable
9. Stationary base plate
10. Knurled screw
11. Pointer
12. Tightening screw
13. Saw shaft lockt
14. Debris bag
15. Scale
16. Safety pin
17. Scale (turntable)
18. Setting screw 0°
19. Setting screw 45°
20. Workpiece support
21. Clamping device
22. Table insert
2.2 Items supplied
Please check that the article is complete as spe-
cifi ed in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Important!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Crosscut and miter saw
•
Carbide-tipped saw blade
•
Allen key (c,d)
•
Sawdust bag (14)
•
Workpiece support (20)
•
Clamping device (21)
•
Original operating instructions
•
Safety instructions
Anl_TH_MS_2112_SPK7.indb 19Anl_TH_MS_2112_SPK7.indb 19 07.05.12 08:4507.05.12 08:45

EINHELL TH-MS 2112 Specifications

General

Input power	1600 W
Output power	1400 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Blade diameter	210 mm
Number of teeth	48
Idle speed (max)	5000 RPM
Cutting depth (90º)	- mm
Cross cut capacity (0° x 0°)	120 x 55 mm
Bevel cut capacity (0° x 45°)	80 x 55 mm
Miter cut capacity (45° x 0°)	120 x 32 mm
Compound cut capacity (45° x 45°)	80 x 32 mm
Saw blade included	Yes
Miter cut	45 - 0 °
Diamond disc	-
Product color	Red

Weight and Dimensions

Depth	480 mm
Width	320 mm
Height	290 mm
Weight	6400 g
Package weight	8700 g
Blade thickness	30 mm
