EINHELL TH-MS 2112 Original Operating Instructions

GB
- 21 -
Warning!
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 General information
•
The equipment must be set up where it can
stand securely, i.e. it should be bolted to a
workbench, a universal base frame or similar.
•
All covers and safety devices have to be pro-
perly fitted before the equipment is switched
on.
•
It must be possible for the blade to run freely.
•
When working with wood that has been pro-
cessed before, watch out for foreign bodies
such as nails or screws, etc.
•
Before you actuate the On/Off switch, make
sure that the saw blade is correctly fitted
and that the equipment’s moving parts run
smoothly.
5.2 Setting up the saw (Fig. 3)
The workpiece supports must be inserted and
tightened using a Phillips screwdriver.
Screwdriver not included in delivery.
5.3 Adjusting the saw (Fig. 1/2)
•
To adjust the turntable (8), loosen the knurled
screw (10) by approx. 2 turns, which frees the
turntable.
•
The turntable has locking points at angles
of 0°, 5°, 10°, 15°, 22,5°, 30°, 35°, 40°, 45°.
Once the turntable is engaged, the setting
must be additionally secured by tightening
the knurled screw (10).
•
If different angle settings are required, the
turntable (8) may be secured in position using
only the knurled screw (10).
•
Lightly press the machine head (4) down
while at the same time pulling the retaining
pin (16) out from the motor mounting; this
causes the saw to move down to the lower
working position.
•
Swing up the machine head (4).
•
By loosening the lock screw (12), the machi-
ne head (4) can be angled to the left up to
45°.
•
Check that the voltage marked on the rating
plate is the same as your mains voltage and
connect up the machine.
Anl_TH_MS_2112_SPK7.indb 21Anl_TH_MS_2112_SPK7.indb 21 07.05.12 08:4507.05.12 08:45

EINHELL TH-MS 2112 Specifications

General

Input power	1600 W
Output power	1400 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Blade diameter	210 mm
Number of teeth	48
Idle speed (max)	5000 RPM
Cutting depth (90º)	- mm
Cross cut capacity (0° x 0°)	120 x 55 mm
Bevel cut capacity (0° x 45°)	80 x 55 mm
Miter cut capacity (45° x 0°)	120 x 32 mm
Compound cut capacity (45° x 45°)	80 x 32 mm
Saw blade included	Yes
Miter cut	45 - 0 °
Diamond disc	-
Product color	Red

Weight and Dimensions

Depth	480 mm
Width	320 mm
Height	290 mm
Weight	6400 g
Package weight	8700 g
Blade thickness	30 mm
