Rear
17
1613 14
12
11
10
9
8
15
10
6. Handle This handle is used for transportation.
7. Security lock slot Complies with Kensington’s MicroSaver security system.
8. Lock button Use this button to remove the monitor from the stand.
9. Headphone jack Connects to headphones.
10. USB-A connector
(downstream)
Connects to a peripheral USB device (page 36).
11. Cable holder Holds the monitor cables.
12. Stand
*1
Adjusts the height and angle (tilt and swivel) of the monitor.
13. Main power switch
Turns the main power on or o.
: On, : O
14. Power connector Connects the power cord.
15. DisplayPort
connector
Connects to a PC with DisplayPort output.
16. HDMI connector
Connects to a PC with HDMI output.
17. USB-C connector
(upstream)
Connects to a PC with USB-C output. This also transmits the USB signal that is
necessary for using software that requires USB connection.
*1 An optional arm (or optional stand) can be attached by removing the stand section.
10
Chapter 1 Introduction
