EK-Quantum Vector Strix RTX 3080 D-RGB - Water Block Specifications and Main Parts

- 6 -
WATER BLOCK SPECIFICATIONS AND MAIN PARTS
TOP PL ATE
(PLEXI / ACETAL)
O-RING
176 x 2
M4/M2,5 x 6,6 STANDOFF
M4/M2,5 x 2,5 STANDOFF - SHORT
COLDPLATE (COPPER / NICKEL)
JET
PL ATE
LED
D-RGB STRIP
M4/M2,5 x 2,5
STANDOFF - LONG
M4 x 27 DIN7984 SCREW
TERMINAL (PLEXI / ACETAL)
O-RING 15x1
M4 x 8 DIN7984 SCREW
EK BADGE
STANDOUT
(BLACK / WHITE)
Technical Specification:
- Dimensions: (LxHxW) - 293x154x16.4mm
- D-RGB (Adressable RGB) cable length: 500mm
- D-RGB LED count: 12
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
