EK-Quantum Vector2 Strix RTX 3080 D-RGB - Fittings and Tubing Installation; Step 1: Connecting Fittings and Plugs

- 17 -
FITTINGS AND TUBING
STEP 1
Screw-in two (2) G1/4 threaded male fittings. Attach the liquid
cooling tubes and connect the water block to the cooling loop
Do not forget to plug the remaining two openings using
the enclosed EK-Plug G1/4 or its equivalent.
EK recommends using EK fittings with all EK water blocks.
CAUTION: When using connectors other than EK
fittings, pay special attention to the length of the fittings’
male G1/4” thread – 5mm is the maximum G1/4” thread
length allowed!
STEP 1
TUBING
EK- PLUG G1/4
EK-FITTING
For this step, you will need:
EK-Loop Multi Allen Key
