SERVICE MANUAL
- 28 - SM-eVENT-GB-3_8-2006.doc
CHANGE 1
Description
• Castors φ 50mm with connecting thread M8 are changed by castors φ 75mm with connecting
thread M10.
Validity
• Type eVENT DK50 D - from serial number A0941-9-05
• Type eVENT DK50 DM - from serial number B0479-9-05
Range
• 3. TECHNICAL DATA
TYPE DK50 D DK50 DM
Dimensions of compressor
w x d x h
mm 400x430x780 400x500x780
Dimensions of packaging
w x d x h
mm 500x530x850 500x600x850
• 15. LIST OF SPARE PARTS
12. Castor with brake MKR-JM-S-75 029000058
13. Castor MKR-S-75 029000059
CHANGE 2
Description
• Termo switches TH63 are changed by switches 2450 RH.
Validity
• Type eVENT DK50 D - from serial number A1315-02-06,
include serial numbers from A-1295-02-06 to 1304-02-06
• Type eVENT DK50 DM - from serial number B0740-03-06
Range
• 15. LIST OF SPARE PARTS
28. Termo switch 2450 RH, 80°C 033510005
29. -
30. Termo switch holder 4KB-576 023000331
31. Termo switch 2450 RH, 40°C 033510004
32. -
