Ekso Bionics EVO Exoskeleton - Fit Guide Tables

5 EVO Sizing and Fit Adjustments
108842 A
Figure 4: Hip Belt Slot Positions
Figure 5: Upper
Torso Tube
Positions
Fit Guide Tables
Table 1: Belt Size
Table 2: Arm Cuff Size
Arm Cuff Measurement
Arm Cuff Size
in
cm
S
9 - 11.5
22.9 - 29.2
M
11.5 - 14
29.2 - 35.6
L
14 - 17
35.6 - 43.2
XL
17 - 20
43.2 - 50.8
Table 3: Torso Length
Belt Size Measurement
Hip-to-Hip Distance
Hip Belt Slot
Setting
in
cm
S/M WING
1
19 - 22.5
48.3 - 57.2
2
22.5 - 24
57.2 - 61
3
24 - 25.5
61 - 64.8
4
25.5 - 27
64.8 - 68.6
5
27 - 28.5
68.6 - 72.4
L/XL WING
1
28.5 - 30
72.4 - 76.2
2
30 - 31.5
76.2 - 80
3
31.5 - 33
80 - 83.8
4
33 - 34.5
83.8 - 87.6
5
34.5 - 36
87.6 - 91.4
Torso Length
Lower Torso Tube
Size
Upper Torso Tube
Position
in
cm
SMALL TUBE
1
14 - 14.6
35.5 - 37
2
14.6 - 15.2
37 - 38.5
3
15.2 - 15.7
38.5 - 40
4
15.7 - 16.3
40 - 41.5
5
16.3 - 16.9
41.5 - 43
6
16.9 - 17.5
43 - 44.5
LARGE TUBE
1
16.9 - 17.5
43 - 44.5
2
17.5 - 18.1
44.5 - 46
3
18.1 - 18.7
46 - 47.5
4
18.7 - 19.3
47.5 - 49
5
19.3 - 19.9
49 - 50.5
6
19.9 - 20.5
50.5 - 52
