Impression 444 – Owner's manual
33
Choice of row for entry
Negative change in value
Positive change in value
Saving data and return to state of tank
Possible number of displayed tanks:
1-4
Show:
0 = show state in liters (l)
1 = show state in percentage (%)
Language:
Language setting is possible in menu
Contrast:
Possibility to set monitor brightness
Tank settings:
In the settings, it is possible to define size in liters, type of tank and compensational value for
each individual tank (see table).
Key functions:
Arrow – choice of data for entry
Plus – positive change in value
Minus – negative change in value
Return – saves data and returns to show state of tank
Settings:
Tank size (1-4) tanks 1….4 4000l step is 5l
Tank type (1-4) for each tank there is a choice of five settings (see table)
Tank type
Measuring instrument
Measuring range
Comments
Water
Fuel
Fecal
Waste
Gas
0
1
2
3
4
Philippi TRG
6 stages
5
6
7
8
9
Philippi TGT / TGW
5 – 180 ohm
Manual
10
11
12
13
14
4 – 20 mA
15
16
17
18
19
0 – 10 V
20
21
22
23
24
240 – 33 ohm
25
26
27
28
29
300 – 10 ohm
30
31
32
33
34
90 – 0 ohm
Kompensation 51
Tanktype 00
Tankvolumen 110
