Impression 444 – Owner's manual
34
35
36
37
38
39
0 – 90 ohm
Optional
40
41
42
43
44
Five inches mater
4 stages
WARNING:
Change settings of the tank type only for defined equipment (for example
0-4, 5-9,…).
Some equipment requires manual changes, which can be carried out only
by the manufacturer of equipment.
If the equipment and settings do not correspond, than the measured data
could be wrong.
Operating the program:
 When any key is touched, the illumination of the monitor is turned on for 30s.
 Via connection B on the back, permanent illumination of monitor can be turned on.
Key 1 Key 2 Key3 Key4
Key 1
Quick touch of the key
Tank 1 settings
Long touch of the key (cca. 5s)
Key 2
Quick touch of the key
Tank 2 settings (if there are more tanks)
Key 3
Quick touch of the key
Tank 3 settings (if there are more tanks)
Key 4
Quick touch of the key
Tank 4 settings (if there are more tanks)
Long touch of the key (cca. 5s)
General settings: tank settings…
Too-low voltage alarm:
If the value of the battery is less than 10,8V for 12V voltage or 21,6V for 24V voltage or if it is
greater than the value 15V for 12V voltage i.e. 30V for 24V voltage, that is shown by a
blinking battery symbol (sign).
Tank compensation:
A special setting – correction is required for irregularly-shaped tanks. With the help of
compensation values, the representation can be adapted so that it is as realistic as possible.
For data entry, the tank when it is half full (that is half the tank), is required.
Examples:
