DMX OPERATOR PRO
38
8.7 MIDI Channel Set Up
These settings only need to be set if you are linking a MIDI device to DMX Operator Pro’s MIDI
input. The MIDI channel set up option allows you to set the desired Midi channel into the DMX
Operator Pro.
(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
1. CF CARD ↓
2. ASSIGN CH.
(2) Press the "DOWN" button four (4) times so that the cursor is now flashing over the #
5 "MIDI CH." option. The LCD will display the following with the cursor box now
flashing over the #5 option.
4. DISPLAY MODE
5. MIDI CH.
(3) Press the "Record" button to enter the MIDI channel option. The LCD will display the
following:
MIDI CH. <01>
OK ESC UP DOWN
(4) Use the "UP" or “DOWN” button to change the MIDI channel setting <1-16>.
(5) Once changed, press the “RECORD” button to confirm and store your new setting.
(6) Press the “ESC” button two (2) times to exit.
