29 SNIPER 2R™ User Manual ver 3
OFFSET ADJUSTMENTS – Calibration
ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THESE FUNCTIONS.
This function allows small adjustments to be made to the PAN and TILT home
positions, the ECCENTRIC drive, the COLOR and GOBO wheels, the SHUTTER, PRISM
and PRISM ROTATION effects, to compensate for ware and/or in the event a sensor
has been knocked slightly out of place.
To access the OFFSET ADJUSTMENTS MENU press and release the MENU button and
immediately press and hold the ENTER button for at least 5 seconds. The fixture will
now be in the OFFSET ADJUSTMENTS MENU where you can make adjustments to the
functions listed below.
To exit the OFFSET ADJUSTMENTS MENU press and hold the MENU button for at least 3
seconds, until the display shows ELATION SNIPER.
SHUTTER AND BEAM POSITION AFTER EXITING OFFSET ADJUSTMENTS MENU
The SHUTTER and BEAM POSITION after exiting the OFFSET ADJUSTMENT MENU will
depend on the DMX STATE setting (“Blackout” or “Last State”) and/or if the fixture is
receiving a DMX signal.
ELATION© SNIPER 2R™
O F F S E T A D J U S T M E N T S M E N U - VERSION 3
Specifications are subject to change without any prior written notice.
MENU
OPTIONS / VALUES
DESCRIPTION
Pan Offset
(0) - (255)
Adjustment The PAN Home Position
Tilt Offset
(0) - (255)
Adjustment The TILT Home Position
Eccentri
(-127) - (127)
Adjustment of the Eccentric Drive
Color Offset
(-127) - (127)
Adjustment of the Color Wheel
Gobo Offset
(-127) - (127)
Adjustment of the Gobo Wheel
Shutter Offset
(0) - (255)
Adjustment of the Shutter
Rprism Offset
(-127) - (127)
Adjustment of the Prism Rotation
Prism Offset
(-127) - (127)
Adjustment of the Prism




