DMX CHANNEL FUNCTIONS AND VALUES
ELATION© SNIPER 2R™
DMX Channel Values / Functions Version 3 (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction of effects depends on the orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
14
16
18
20
1
1
PAN
0-127
PAN Movement
128-255
PAN Shaking Movement SLOW to FAST
1
1
PAN
0-255
PAN Movement
2
2
2
PAN FINE [16 BIT]
0-255
PAN Movement FINE [16bit]
2
3
TILT
0-127
TILT Movement
128-255
TILT Shaking Movement SLOW to FAST
3
3
TILT
0-255
TILT Movement
4
4
4
TILT FINE [16 BIT]
0-255
TILT Movement FINE
5
5
PAN SHAKING MOVEMENT SPEED
0-255
PAN Shaking Movement SLOW to FAST
6
6
TILT SHAKING MOVEMENT SPEED
0-255
TILT Shaking Movement SLOW to FAST
3
5
7
7
COLORS
0-2
WHITE
3-4
Spilt WHITE / LIGHT RED
5-6
LIGHT RED
7-8
Split LIGHT RED / BLUE
9-11
BLUE
12-13
Split BLUE / GREEN
14-15
GREEN
16-17
Split GREEN / YELLOW
18-20
YELLOW
21-22
Split YELLOW / ORANGE
23-24
ORANGE
25-26
Split ORANGE / MAGENTA
27-29
MAGENTA
30-31
Split MAGENTA / LAVENDAR
32-33
LAVENDAR
34-35
Split LAVENDAR / LIGHT PINK
36-38
LIGHT PINK
39-40
Split LIGHT PINK / YELLOW-GREEN
41-42
YELLOW GREEN
43-44
Split YELLOW-GREEN / PEACOCK BLUE
45-47
PEACOCK BLUE
48-49
Split PEACOCK BLUE / MEDIUM PINK
50-51
MEDIUM PINK
