31 SNIPER 2R™ User Manual ver 3
ELATION© SNIPER 2R™
DMX Channel Values / Functions Version 3 (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction of effects depends on the orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
14
16
18
20
COLORS [continued]
3
5
7
7
52-53
Split MEDIUM PINK / MEDIUM PURPLE
54-56
MEDIUM PURPLE
57-58
Split MEDIUM PURPLE / PINEAPPLE YELLOW
59-60
PINEAPPLE YELLOW
61-62
Split PINEAPPLE YELLOW / CONGO BLUE
63-65
CONGO BLUE
66-67
WHITE
68-128
Color Wheel Index - WHITE to CONGO BLUE
129-190
*Clockwise Color Rotation from FAST to SLOW
191-193
STOP
194-255
*Counterclockwise Color Rotation from SLOW to FAST
4
6
8
8
GOBOS
0-7
OPEN
8-14
Gobo 1
15-22
Gobo 2
23-29
Gobo 3
30-37
Gobo 4
38-44
Gobo 5
45-52
Gobo 6
53-59
Gobo 7
60-67
Gobo 8
68-74
Gobo 9
75-82
Gobo 10
83-89
Gobo 11
90-97
Gobo 12
98-104
Gobo 13
105-112
Gobo 14
113-119
Gobo 15
120-126
Gobo 16
127-133
Gobo 17
134-194
*Clockwise Gobo Wheel Rotation From FAST to SLOW
195-255
*Counterclockwise Gobo Wheel Rotation From SLOW to FAST
