32 SNIPER 2R™ User Manual ver 3
ELATION© SNIPER 2R™
DMX Channel Values / Functions Version 3 (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction of effects depends on the orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
14
16
18
20
5
7
9
9
PATTERN MACROS
0-8
OFF
9-16
Pattern Macro 1
17-25
Pattern Macro 2
26-33
Pattern Macro 3
34-42
Pattern Macro 4
43-50
Pattern Macro 5
51-59
Pattern Macro 6
60-67
Pattern Macro 7
68-76
Pattern Macro 8
77-84
Pattern Macro 9
85-93
Pattern Macro 10
94-101
Pattern Macro 11
102-110
Pattern Macro 12
111-118
Pattern Macro 13
119-127
Pattern Macro 14
128-135
Pattern Macro 15
136-144
Pattern Macro 16
145-152
Pattern Macro 17
153-161
Pattern Macro 18
162-169
Pattern Macro 19
170-178
Pattern Macro 20
179-186
Pattern Macro 21
187-195
Pattern Macro 22
196-203
Pattern Macro 23
204-212
Pattern Macro 24
213-220
Pattern Macro 25
221-229
Pattern Macro 26
230-237
Pattern Macro 27
238-246
Pattern Macro 28
247-255
Pattern Macro 29
6
8
10
10
PATTERN ROTATION - *CLOCKWISE / *COUNTERCLOCKWISE
0-9
STOP
10-120
*Clockwise Pattern Rotation from FAST to SLOW
126-141
STOP
142-245
*Counterclockwise Pattern Rotation from SLOW to FAST
246-255
STOP
7
9
11
11
PATTERN ROTATION - *HORIZONTAL / *VERTICAL
0-9
STOP
10-120
*Horizontal Pattern Rotation from FAST to SLOW
121-134
STOP
135-245
*Vertical Pattern Rotation from SLOW to FAST
246-255
STOP
