33 SNIPER 2R™ User Manual ver 3
ELATION© SNIPER 2R™
DMX Channel Values / Functions Version 3 (20 DMX Channels)
Specifications are subject to change without any prior written notice.
*Rotation direction of effects depends on the orientation of the fixture head.
MODE / CHANNEL
VALUE
FUNCTION
14
16
18
20
8
10
12
12
PATTERN ZOOM
0-127
Pattern ZOOM Manual
128-255
Pattern ZOOM SLOW to FAST
9
11
13
13
BEAM ROTATION
0-63
0° to 360°
64-127
Shaking
128-189
*Clockwise Rotation FAST to SLOW
190-193
STOP
194-255
*Counterclockwise Rotation SLOW to FAST
10
12
14
14
PRISM
0-7
PRISM OFF
8-255
PRSIM ON
11
13
15
15
PRISM ROTATION
0-127
PRISM Indexing
128-189
*Clockwise PRISM Rotation FAST to SLOW
190-193
STOP
194-255
*Counterclockwise PRISM Rotation SLOW to FAST
12
14
16
16
SHUTTER, STROBE
0-7
BLACKOUT
8-15
OPEN
16-131
STROBE SLOW to FAST
132-139
OPEN
140-181
FAST OPEN to SLOW CLOSE
182-189
OPEN
190-231
FAST CLOSE to SLOW OPEN
232-239
OPEN
240-247
RANDUM STROBE
248-255
OPEN
13
15
17
17
DIMMER INTENSITY
0-255
Dimmer Intensity 0 to 100%
14
16
18
18
FUNCTIONS
0-39
NO FUNCTION
40-59
LAMP ON
60-79
LAMP OFF
80-84
ALL MOTORS Reset
85-87
PAN / TILT Motors Reset
88-90
COLOR Motor Reset
91-93
GOBO Motor Reset
94-96
SHUTTER & DIMMER Motors Reset
97-99
OTHER Motors Reset
100-109
ENABLE BLACKOUT WHILE PAN/TILT MOVEMENT
110-119
ENABLE BLACKOUT WHILE COLOR CHANGE
120-129
ENABLE BLACKOUT WHILE GOBO CHANGE
130-255
NO FUNCTION
