Elba ELIO E93 MF - INSTALLATION

9
INS TALLATIO N
1
min. 900 mm.
857 mm
895 mm
595 mm
580 mm
min. 860 mm
600 mm
550 mm
23 mm
min. 550 mm
857 mm
895 mm
595 mm
550 mm
23 mm
min. 550 mm
580 mm
min. 860 mm
600 mm
Fig. 1.1a
Fig. 1.1b
IMP O R TANT
• The oven can be tted in
standard units, width 90 cm
and depth 55 cm.
• Installation requires a
compartment as illustrated in
gures 1.1a and 1.1b.
• On the lower side, the
oven must lay on supports
standing the oven weight.
• Remember the housing
should not be free standing
but be secured to the wall
and/or adjacent ttings.
W AR NING
• W e w o u l d p o i n t o u t t h a t t h e
a d h e s i v e w h i c h b o n d s t h e p l a s t i c
l a m i n a t e t o t h e f u r n i t u r e m u s t
w i t h s t a n d t e m p e r a t u r e s n o t l e s s
t h a n 1 5 0 ° C t o a v o i d
d e l a m i n a t i o n .
• Th e w a l l s o f t h e u n i t s
m u s t b e c a p a b l e o f
r e s i s t i n g t e m p e r a t u r e s
o f 7 5 ° C a b o v e r o o m
t e m p e r a t u r e .
• Do n o t s e a l t h e o v e n
i n t o t h e c a b i n e t r y
w i t h s i l i c o n e o r g l u e ;
t h i s m a k e s f u t u r e
servicing di󰀩cult.
Th e m a n u f a c t u r e r w i l l
n o t c o v e r t h e c o s t s o f
r e m o v i n g t h e o v e n , o r o f
d a m a g e c a u s e d b y t h i s
r e m o v a l .
• Th e w a l l s s u r r o u n d i n g
t h e o v e n m u s t b e
m a d e o f h e a t - r e s i s t a n t
m a t e r i a l .
• W AR NING : Ta k i n g c a r e
NO T t o l i f t t h e o v e n b y
t h e d o o r h a n d l e .
