Elba PXDO 906 DF - Removing the Oven Door

24
The oven door can easily be removed as
follows:
– Open the door to the full extent (fig.
7.7A).
– Attach the retaining rings to the hooks
on the left and right hinges (fig. 7.7B).
– Hold the door as shown in fig. 7.7.
– Gently close the door and withdraw the
lower hinge pins from their location
(fig. 7.7C).
– Withdraw the upper hinge pins from
their location (fig. 7.7D).
– Rest the door on a soft surface.
– To replace the door, repeat the above
steps in reverse order.
Fig. 7.7D
Fig. 7.7C
Fig. 7.7B
Fig. 7.7A
REMOVING THE OVEN DOOR
Fig. 7.7
