elco Combi 24 - Page 45

45
Parameters technician
Menu Line no. Selection possibilities Unit Min. Max Factory setting
I/O-Test 7700 Relay test - 0: No test
1:Everythingo󰀨
2: Relay output QX1
3: Relay output QX2
4: Relay output QX3
5: Relay output QX4
6: Relay output QX21 module 1
7: Relay output QX22 module 1
8: Relay output QX23 module 1
9: Relay output QX21 module 2
10: Relay output QX22 module 2
11: Relay output QX23 module 2
12: Relay output QX21 module 3
13: Relay output QX22 module 3
14: Relay output QX23 module 3
No test
7713 Output test P1 %
0 100
---
7714 PWM output P1 %
0 100
0
7730 Outside temp B9 °C
-50 50
0
7750 DHW temp B3/B38 °C
0 140
0
7760 Boiler temp B2 °C
0 140
0
7820 Sensor temp BX1 °C -28 350 0
7821 Sensor temp BX2 °C -28 350 0
7822 Sensor temp BX3 °C -28 350 0
7823 Sensor temp BX4
°C -28 350 0
7830 Sensor temp BX21 module 1
°C -28 350 0
7831 Sensor temp BX22 module 1 °C
-28 350
0
7832 Sensor temp BX21 module 2 °C
-28 350
0
7833 Sensor temp BX22 module 2 °C
-28 350
0
7834 Sensor temp BX21 module 3 °C
-28 350
0
7835 Sensor temp BX22 module 3 °C
-28 350
0
7840 Voltage signal H1 V
0 10
0
7841 Contact state H1 -
Open, Closed
Open
7845 Voltage signal H2 module 1 V
0 10
0
7846 Contact state H2 module 1 -
Open, Closed
Open
7848 Voltage signal H2 module 2 V
0 10
0
7849 Contact state H2 module 2 -
Open, Closed
Open
7851 Voltage signal H2 module 3 V
0 10
0
7852 Contact state H2 module 3 -
Open, Closed
Open
7854 Voltage signal H3 V
0 10
0
7855 Contact state H3 -
Open, Closed
Open
7862 Frequency H4 -
0
0
7860 Contact state H4 -
Open, Closed
Open
7865 Contact state H5 -
Open, Closed
Open
7872 Contact state H6 -
Open, Closed
Open
7874 Contact state H7 - Open, Closed Open
7950 Input EX21 module 1 -
0V, 230V
0V
7951 Input EX21 module 2 -
0V, 230V
0V
7952 Input EX21 module 3 -
0V, 230V
0V
Status 8000 State heating circuit 1 - 0: ---
1: STB tripped
. . . . . . . .
254: Value 550; 254
255: Value 550; 255
---
8001 State heating circuit 2 - ---
8002 State heating circuit 3 - ---
8003 State DHW - ---
8005 State boiler - ---
8007 State solar - ---
8008 State solid fuel boiler - ---
8009 State burner - ---
8010 Statebu󰀨er - ---
8011 State swimming pool - ---
