Technical data
Power supply Rated voltage AC 230 V (+10% / -15%)
Rated frequency 50 Hz (± 5%)
Maximum power consumption LMS 14, 17 VA
Terminal wiring (power supply and output terminals) Lead or braided wire
(twisted or with wire end ferrule):
1 lead: 0.5 mm
2
...2.5 mm
2
2 leads: 0.5. mm
2
..1.5 mm
2
Functional data Software class Control component class A
Firing automat class C
Functionality according to EN 60730 1b (automated functionality)
Ingangen Safety shutdown
Gas pressure monitor
Programmable input terminal
Room thermostat 1 and 2
RAC 26 V
at 10 mA
Sensor input terminal - outdoor sensor
Sensor input terminals: Boiler preheating, boiler
return, storage sensor, sensor at
clip IN AGU 2500, 2514
NTC1k (QAC34)
NTC10k (QAZ36, QAD36)
Permitted sensor wires (Cu)
With a wire diameter of: 0.25 0.5 0.75 1.0 1.5 (mm
2
)
Maximum length: 20 40 60 80 120 (m)
Output terminals Relay output terminals
Rated current range
Maximum overall current (all relays)
Rated voltage range
AC 0.05...1 (1) A for fuel valve and external
ignition 0.5 A
AC 5 A
AC (230) V (+ 10 % / - 15 %)
Interfaces BBSB
Max. wire length
LMS 14 peripheral devices
Max. total wire length
Minimum wire cross-section
2-lead connection not exchangeable
200 m
400 m (max. cable capacity: 60 nF)
0.5 mm
2
Protection type and protection
class
Housing protection type in conformity with EN
60529
IPX0D
Protection class according to EN 60730 Low-voltage components conform to the
requirements of protection class II, if they are
properly installed
Contamination level according to EN 60730 2
Normen, veiligheid, EVM enz. CE conformity according to
EMC Directive
Low-voltage Directive
89/336/EWG
73/23/EWG
Climatic conditions Storage according to IEC721-3-1 Class 1K3 Temp. -20…60°C
Transport according to IEC721-3-2 Class 2K3 Temp. -20…60°C
Operation according to IEC721-3-3 Class 3K3 Temp. 0...60°C (without condensation)
