3.3 SELECTING THE MEASUREMENT UNITS
The Elcometer 215 can display readings in °C or °F. The default
setting is °C.
To change the measurement units:
1 If idle, press the ‘Func’ key to wake the logger.
2 Repeatedly press the ‘Func’ key until ‘SET’ is displayed.
3 Repeatedly press the ‘Sel’ key until ‘SET range’ is displayed.
4 Press and hold the ‘Set’ key for approximately 5 seconds whilst
‘Hold to change’ is displayed.
5 Press the ‘Set’ key to select the required measurement units.
°C Range: -200/1300°C; °F Range: -328/2372°F
6 Press the ‘Func’ key to exit the menu.
Note: Any runs stored in the logger must be deleted before changing the measurement
units, see Section 4.5 ‘Clearing the Memory’ on page en-8.
3.4 SETTING THE DATE FORMAT
1 If idle, press the ‘Func’ key to wake the logger.
2 Repeatedly press the ‘Func’ key until ‘SET’ is displayed.
3 Repeatedly press the ‘Sel’ key until ‘SET format’ is displayed.
4 Press and hold the ‘Set’ key for approximately 5 seconds whilst
‘Hold to change’ is displayed.
5 Press the ‘Set’ key to select the required date format.
DD/MM/YY, MM/DD/YY or YY/MM/DD
6 Press the ‘Func’ key to exit the menu.
3.5 SETTING THE TIME AND DATE
1 If idle, press the ‘Func’ key to wake the logger.
2 Repeatedly press the ‘Func’ key until ‘TIME/date’ is displayed.
3 Press and hold the ‘Set’ key for approximately 5 seconds whilst
‘Hold to change’ is displayed.
4 Set the date and time using the ‘Sel’ and ‘Set’ keys.
5 Press the ‘Func’ key to exit the menu.
3.6 SETTING THE LOGGING INTERVAL
The Elcometer 215 measures continuously but takes and saves
readings at time intervals set the by user ranging from 0.125 s
(8 readings per second) to 2 hours. The default setting is every
2 seconds.
3 GETTING STARTED (continued)
www.elcometer.com
en-4
