3 GETTING STARTED (continued)
b
Other time / temperature combination thermal barriers are available on request. Please contact
Elcometer or your local supplier for further details.
4.1 BEFORE YOU START
1 Set-up the logger, see Section 3.2 to 3.6 on page en-3.
2 Connect the probes, see Section 3.7 on page en-5.
3 Place the logger in the heat sink block (if required) and thermal
barrier.
4.2 START LOGGING
The Elcometer 215 can store up to 260,000 readings in up to 8 production
runs.
To start logging:
1 If idle, press the ‘Func’ key to wake the logger.
2 Repeatedly press the ‘Func’ key until ‘LOG no runs’ is displayed.
3 Press and hold the ‘Set’ key for approximately 5 seconds whilst
‘Hold to start’ is displayed, logging will commence.
®
The logger can be pre-programmed via ElcoMaster to start logging
immediately after holding the ‘Set’ key; after a set period; when a set
temperature has been reached or when the rate of temperature
increase rises above a set value - see Appendix A: Section A.2
‘Creating a Settings File’ on page en-14 for further details.
4.3 STOP LOGGING
Logging will stop when the maximum run time has been reached
®
unless the logger is pre-programmed via ElcoMaster to stop after a
set time period has elapsed or the temperature falls below a set
value, see Appendix A: Section A.2 ‘Creating a Settings File’ on page
en-14 for further details.
4 USING THE LOGGER
www.elcometer.com
en-7
