7(&+1,&$/'$7$
Battery power supply 12 Vdc and 24 Vdc
Supply voltage
8 ÷ 32V
Selfconsumption with engine stopped 6 mA at 12V 4 mA at 24V
Selfconsumption with stopped engine and pressed
emergency button
170 mA at 12 V 100 mA at 24V
Max consumption 210 mA at 12V 145 mA at 24V
Rated insulation voltage:
• Terminal board of battery
32V
15 (starting) 0,25A, 6 (glow plugs) 0,25A,
17 (stopping) 1,5A, 19 (key) 0,25A,
Max load of the outputs
70 (general alarm) 0,25A.
Degree of rear protection IP00
Degree of front protection IP64
Temperature range
−
20 ÷ + 50 ºC
Weight 410 g
Dimensions (LxHxP)mm 157x109x52
Hole mm 88x137
Hour-meter 5 digits
Tachometer Max 4000 RPM precision ± 10 RPM
ORDERING DATA
Type DCA- 110 code 24.22.63
CONFORMITY DECLARATION
ELCOS s.r.l. assumes full responsability for declaring that the control unit:
type
DCA-110
installed and used in the ways and for the purposes described in the
instruction and user manual, is in conformity with the following directives:
- 2006/95/CE related to the electrical materials destined to be used within
certain voltages limits
- 2004/108/CE related to the electromagnetic compatibility and that repeals
the directive 89/336/CEE,
because it is built and functions in accordance with the harmonized Standards:
EN61010-1, EN61326-1, EN61326/A1, EN61000-4-2, EN61000-4-3,
EN61000-4-4, EN61000-4-5, EN61000-4-6, EN60529.
®
(PDLOLQIR#HOFRVLW+773ZZZH OFRVLW
9LD1DYLJOLR$OWRD
3$50$,7$/,$
6UO
)D[
7HO
Walter Consigli
Parma, 20/02/2009
President
ACCESSORIES SUPPLIED
KIT MU-DCA-110 code 80.44.33
