9-6
HOW TO USE YOUR MOTORHOME’S EQUIPMENT
The refrigerator is equipped to operate on
three power modes:
• Mains voltage (230V AC)
•Direct current voltage (12V DC)
• Gas (liquid gas, propane/butane)
Select the desired power mode by the energy
selector switch (battery igniter type models)
or the energy selector button (MES, AES).
Appliances with automatic energy selection
(AES) are additionally provided with
“automatic mode” function. Then the AES
system automatically selects the best energy
source for each particular situation.
The cooling unit is silent in operation.
When the appliance is first put into operation,
there may be a mild odour which will
disappear after a few hours.
The refrigerator will take several hours to
reach its operating temperature in the cooling
compartment. The freezer compartment
should be cold about one hour after switching
on the refrigerator.
Cleaning
Before starting up the refrigerator, it is
recommended that you clean it inside and
repeat this at regular intervals.
Use a soft cloth and lukewarm water with a
REFRIGERATOR
Your new Elddis Motorhome is fitted with a Dometic refrigerator. Details of how to operate your
fridge are shown below:
mild detergent. Then wipe out the appliance
with clean water and dry thoroughly.
To avoid material alterations, do not use soap
or hard, abrasive or soda-based cleaning
agents. Do not allow the door seal to come
into contact with oil or grease.
Maintenance
In compliance with applicable regulations,
please note that the gas unit and the
connected ventilation ducts must be checked
by an authorised technical personnel after
first use and after every other year for
compliance with the European Standard EN
1949. A test certificate has to be issued. It is
the user’s responsibility to arrange this
test.
The gas burner must be inspected and
cleaned as necessary, at least once a year.
When using liquefied petroleum gas (tank or
refill cylinders) the maintenance interval is
reduced to half-yearly or quarterly.
Keep the evidence of maintenance work
carried out on your refrigerator.
1 Operating controls.
2 Door locking button.
3 Freezer compartment (removable)
4Insertable grid shelf (available as option,
to be used when freezer compartment is
removed).
5 Post-evaporator for cooling compartment.
6 Condensation water drain channel.
7Vegetable bin.
8 Upper door shelf with flap, egg shelf
available as option may be inserted.
9 Lower door shelf with bottle holders
Fig 1
