9-24
HOW TO USE YOUR MOTORHOME’S EQUIPMENT
Fig 3
Fig 2
Midi Heki Rooflight
(i) To open, push the large central button
(Fig 2).
(ii) Whilst depressed, slide the bar to the
desired position and locate into the stops
provided (Fig 3).
Fig 1
The Omnivent (12v) Rooflight
(Option)
The Omnivent is a double-glazed roof light
constructed from a synthetic ultra-violet
screened material. Its side-operating
mechanism allows a completely free central
opening with built-in fixed ventilation when
closed. It operates as an extractor fan and air
intake fan.
Please note: Do not change the direction of
the fan unless it has been switched off ‘O’
position and the blades have stopped
rotating.
Door Flyscreen
The exterior door flyscreen can be opened or
closed from both inside and outside of the
Motorhome and does not restrict door
openings.
When opening or closing the door flyscreen
use the finger grip provided.
