ESIM264 USER MANUAL V2.3

CONTENTS OF PACK

Element Quantity

1. ESIM264............... .............................................1

2. Microphone.................. .....................................1

3. SMA antenna......... ...........................................1

4. Buzzer........................... .....................................1

5. Back-up battery connection wire... ..............1

6. User manual....................... ...............................1

7. Resistors 5,6kΩ......................... ...................... 6

8. Resistors 3,3kΩ................. .............................. 6

9. Plastic standos................ ............................. 4

1. GENERAL INFORMATION

Functionality

ESIM264 – micro-controller based alarm system for houses, cottages, country homes, garages and other buildings, also capable of manag-

ing electrical appliances via cellular GSM/GPRS network. It can also be used as Intercom system.

Examples of using the system:

• Property security.

• Alarm switch.

• Thermostat, heating and air-conditioner control, temperature monitoring.

• Lighting, garden watering, water pump and other electrical equipment control via SMS text messages.

• Remote listening to what is happening in the secured area.

• Main 230V power status with SMS text message.

• Two-way intercom device via GSM network.

Short Description of Main Denitions

The following table provides the explanation of main denitions which are met in this user manual.

Denition Description

System; alarm system ESIM264 device

SMS Short Message Service text

Keyboard Device with a set keys allowing to congure & control the system, view violated zones & system troubles

EKB2 Model of LCD keyboard

EKB3 Model of LED keyboard

EWK1 Wireless keyfob model

EWK2 Wireless keyfob model

User phone number; User 1... 5 Phone number of the user allowed to control the system

System phone number Phone number of the SIM card inserted in ESIM264 device

User password 4-digit combination intended for system arming/disarming using a keyboard

iButton® key Small metal tab containing a unique ID code intended for system arming/disarming

Zone Alarm system input for wired and wireless sensor connection

PGM output Alarm system output for connection of electrical appliances (heating, lighting, gates etc.)

Partition Section dividing one alarm system into two independent parts software-wise
