ESIM264 USER MANUAL V2.3
3. BASIC CONFIGURATION AND USE
!!! In this installation manual the underscore character ”_” represents one space character. Every underscore character must
be replaced by a single space character. There must be no spaces or other unnecessary characters at the beginning and at
the end of the SMS text message.
3.1. SMS Text Messages
SMS
In order to congure and control the system by SMS text message, send the text command to the ESIM264 system phone
number from one of the listed user phone numbers. The structure of SMS text message consists of 4-digit SMS password
(the default SMS password is 0000 – four zeros), the parameter and value. For some parameters the value does not apply e. g.
STATUS. The variables are indicated in lower-case letters, while a valid parameter value range is indicated in
3.1.1. EKB2 LCD Keypad
EKB2
The system conguration and control by EKB2 keypad is carried out by navigating throughout the menu section list displayed
on LCD screen. To navigate in the menu path, touch ↓, ↑ keys to select the desired menu section and touch OK key to open the
selected section. To enter a required value, use 0... 9 keys and touch OK key for conrmation or cancel/go one menu section
back by touching ← key. The value can be typed in directly by touching 0... 9 keys while highlighting the desired menu sec-
tion. EKB2 menu type is “circle”, therefore when the last section in the menu list is selected, you will be brought back to the
beginning of the list after touching the ↓ key. In this installation manual, the menu path is based on the EKB2 menu tree by
starting at home screen view. The variables are provided in lower-case letters, while a valid parameter value range is provided
in brackets.
NOTE: Menu section CONFIGURATION is secured with administrator password. The default administrator password is 1470.
NOTE: The system can be congured using only one keypad at a time. Other connected keypads will be inactive while the menu section
CONFIGURATION is opened. The inactive EKB2 keypads will display
icon and CONFIGURATION MODE message.
NOTE: The keypad will automatically exit the menu section CONFIGURATION and return to home screen view if 1 minute after the last
key-touch expires.
3.1.2. EKB3 LED Keypad
EKB3
The system conguration and control by EKB3 keypad is carried out by activating the Conguration mode using the adminis-
trator password (by default – administrator password is 1470) and entering a valid conguration command using the number
keys [0]... [9], [#] key for conrmation and [*] key to cancel the characters that are being entered. Alternatively, the user
can wait for 10 seconds until the keypad buzzer will provide a long beep indicating that the entered characters have been
cancelled. When typing in the characters, the indication of each pressed key is provided by short beep of keypad buzzer and
red indicators when the number keys [0]... [9] are being pressed. Some commands require [BYPS], [CODE] and [STAY] keys as
well. The structure of a standard conguration command is a combination of digits. The commands, which do not require the
Conguration mode being activated, are noted. The variables are provided in lower-case letters, while a valid parameter value
range is provided in brackets.
NOTE: If you were not willing to activate Conguration mode, but accidentally typed in the * as the rst character, please press [*] key again
or wait for 10 seconds until the keypad buzzer will provide a long beep indicating that the typed in characters have been cancelled.
Activate/deactivate
Conguration mode
EKB3
Enter administrator password:
* aaaa #
Value: aaaa – 4-digit administrator password.
Example: *1470#
The following table provides a list of EKB3 indications, which are relevant during Conguration mode.
Indication Description
Indicator ARMED ashing Conguration mode activated successfully.
Indicator SYSTEM ashing Valid parameter is entered and waiting for valid value to be entered.
1 long beep Non-existing command or invalid parameter value entered.
3 short beeps Command entered successfully.
NOTE: The system can be congured using only one keypad at a time. Other connected keypads will be inactive while the Congura-
tion mode is activated.
NOTE: Conguration mode will automatically deactivate if 1 minute after the last key-stroke expires.
