SoilTest PRO Auto Soils Consolidator (ASC)
25-0500
Original Instructions 23 9901X0275 Issue 2
Maintenance
Before each test:
Check/clean top plate and uprights.
Check location pin secure.
Check transducers securely mounted.
Check condition of ball seat.
Occasionally:
Check crossbar is level to machine.
Check machine is secure on bench.
Annually:
Calibration of force/displacement transducers.
Service, Spares and Accessories
It is recommended that either the ELE Service Department or an authorised distributor be
contacted for details of available spare parts or servicing requirements.
Full part numbers for the spares used on cells are detailed in a previous section.
Consolidation Cell Range
Other spares/accessories include:-
Water bottle (500 ml) for inundating samples
Spare screen cover and fuses
S Type Load Cell (0.7 m lead)
Displacement Transducer (LVDT) (0.7 m lead)
