Electra DNG 100 - DNG 125 DCI Indoor Unit Spare Parts

15-3
EXPLODED VIEWS AND SPARE PARTS LISTS
SM OU12HP 2-E.2 GB
15.3 Indoor Unit: DNG 125 DCI - Spare Part List
No. Part No. Description Qty
1 473532 IU COIL GR/HDR DNG 125 DCI 1
2 473231 FLOAT SUPPORT DNG 1
3 473902 DNG METAL FILTER 37-44 1
4 473247 INSULATED DRAIN POOL ASSY DNG 1
5 473700 DNG OVER FLOW SWITCH 1
6 473245 COIL SUPPORT DNG 37 1
7 467300107R DCI 456 HP IDU STORM 1
7a 404020 CABLE 8 WIRES 7M WTH CONNECTOR 1
8 438778 WIRED DISPLAY BOX EMD/ELD (RoHS) 1
9 473906 FAN HOUSING ASSY DNG 37-44 1
9a 473006 MOTOR DNG 37/44 1
9b 473301 CENTRIFUGAL FAN DNG 300/130 1
11 473249 AIR FILTER FRAME ASSY DNG 37-4 1
12 473250 MOTOR LEG ASSY DNG 3
16 438783 REMOTE CONTROL RC4/RC (RoHS) 1
17 430535 *TERMINAL BLOCK RW-52 P6/90 1
18 442019 CAPACITOR 8mF 400V P1/P2 1
19a 473720 THERMISTOR+CAP WITH CONNECTOR 1
19b 473710 THERMISTOR WITH CONNECTOR L235 1
28 473415 ELECTRICAL COVER DNG DCI 1
29 473416 ELECTRICAL BASE PANEL DNG DCI 1
Option for External Room Temperature Sensor
40 442297 THERMISTOR BOX AIRWELL 1
41 467030054 SHIELDED DEFROST CABLE 1
42 442296 ADAPTOR THERMISTOR WTH CONNE 1
