AIRFLOW CURVES
SM OU12HP 2-E.2 GB
6. AIRFLOW CURVES
6.1 Model: DNG 100 DCI
6.2 Model: DNG 125 DCI
Air Flow vs. External Static Pressure
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
1,000 1,200 1,400 1,600 1,800 2,000 2,200 2,400
Air Flow [m 3 /h]
]aP[ erusserP citatS lanretxE
Nominal System Curve
Max Sy s tem Cur v e
Medium Speed
Low Speed
High Speed
Perf ormance test
point at 37 Pa
Operating Range
Air Flow vs. External Static Pressure
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
1,000 1,200 1,400 1,600 1,800 2,000 2,200 2,400
Air Flow [m
3
/h]
]aP[ erusserP citatS lanretxE
Nominal Sy s tem Curv e
Max Sy s t e m Cur v e
Mediu m Speed
Low Speed
High Speed
Performance test
point at 50 Pa
Operating Range
