15.5 Indoor Unit: EMD 100 DCI - Spare Part List
No. Part No. Description Qty
1 439978 IU COIL GR/HDR EMD 34/ 100 1
3 402347 AIR FILTER EMD 775-1000 2
4 438032 RT DRAIN PAN ASSY 3/4 EMDB 2 1
7 467300107R DCI 456 HP IDU STORM 1
7a 404020 CABLE 8 WIRES 7M WTH CONNECT 1
8 438778 WIRED DISPLAY BOX EMD/ELD (R 1
9 182241 RT FAN MOTOR DD9*9 CAP. P2 1
9a 402003 MOTOR 343W, 4S, EMD 1100 1
9b 435413 FAN 240*240 1
14 434762 RT OUTLET ASSY EMD 24 R410A 1
15 439980 RIGHT INLET MANIFOLD ASSY EM 1
16 4527178R REMOTE CONTROL RC RC7 GRAY 1
17 430535 *TERMINAL BLOCK RW-52 P6/90 1
18 442015 CAPACITOR 15mF 400V P1/P2 1
19a 400275 THERMISTOR+CAP WTH CONNECTOR 1
19b 402701 THERMISTOR WTH CONNECTORS L1800 1
20 438056 DRAIN SIPHON ASSY 1
28 473415 ELECTRICAL COVER DNG DCI 1
29 473416 ELECTRICAL BASE PANEL DNG DC 1
Option for External Room Temperature Sensor
40 442297 THERMISTOR BOX AIRWELL 1
41 467030054 SHIELDED DEFROST CABLE 1
42 442296 ADAPTOR THERMISTOR WTH CONNE 1
