Electra DNG 100 - EMD 125 DCI Indoor Unit Spare Parts

15-7
EXPLODED VIEWS AND SPARE PARTS LISTS
SM OU12HP 2-E.2 GB
15.7 Indoor Unit: EMD 125 DCI - Spare Part List
No. Part No. Description Qty
1 439991 RT IU COIL GR/HDR EMD 125 DCI 1
3 402083 AIR FILTER EMD 1800 2
4 438069 DRAIN PAN ASSY EMDB60 1
7 467300107R DCI 456 HP IDU STORM 1
7a 404020 CABLE 8 WIRES 7M WTH CONNECTOR 1
8 438778 WIRED DISPLAY BOX EMD/ELD (RoH 1
9 182244 RT FAN MOTOR DD9*11 CAP. P2 EM 1
9a 186320 MOTOR 371W, 4S, EMD1400 1
9b 435410 FAN 253*298 1
15a 433223 SOCKET FLARE ASSY 3/8’’ 1
16 4527178R REMOTE CONTROL RC RC7 GRAY 1
17 430535 *TERMINAL BLOCK RW-52 P6/90 1
18 442018 CAPACITOR 10mF 400V P1/P2 1
19a 400275 THERMISTOR+CAP WTH CONNECTOR L 1
19b 402701 THERMISTOR WTH CONNECTORS L1800 1
20 438056 DRAIN SIPHON ASSY 1
28 473415 ELECTRICAL COVER DNG DCI 1
29 473416 ELECTRICAL BASE PANEL DNG DCI 1
Option for External Room Temperature Sensor
40 442297 THERMISTOR BOX AIRWELL 1
41 467030054 SHIELDED DEFROST CABLE 1
42 442296 ADAPTOR THERMISTOR WTH CONNECT 1
