Electra DNG 100 - OU12 4 HP DCI Outdoor Unit Spare Parts

15-13
EXPLODED VIEWS AND SPARE PARTS LISTS
SM OU12HP 2-E.2 GB
15.11 Outdoor Unit: OU12 4HP DCI - Spare Part List
No. PN Description Qty
1 437045 UPPER COVER EL13 OU LARGE 1
2 416217 SIDE PANEL OU12 DCI 4-5HP 1
3 436356 LARGE ELECTRICAL COVER OU/WMQ 1
4 416215 FRONT COVER OU12 DCI 4-5HP 1
4a 416216 FRONT Panel OU12 DCI 4-5HP 1
5 437091 OU SQUARE FAN GUARD 2
6 416213 NEW BASE ASSY OU12 DCI 4-5HP 1
7 416400 LOWER COIL GR HDR OU12 DCI R41 1
7a 416401 UPPER COIL GR HDR OU12 DCI R41 1
8 4529604 AXIAL FAN D493*143 2
9 416310 DC MOTOR 70W OU12 DCI 4-5HP 2
10 416218 SIDE GUARD OU12 DCI 4-5HP 1
11 436358 OU LEADING HANDLE 1
12 416222 MOTOR SUPPORT ASSEMBLY OU12-DC 1
14 416300 COMPRESSOR ANB33FBDMT 1
15 416534 Tubing Assembly EEV OU12 DCI 1
16 416543 Tubing Assembly 4-Way OU12 4HP DCI 1
19a 413712 THERMISTOR+CAP WITH CONNECTOR 1
19b 402741 THERMISTOR WTH CONNECTOR L1250 1
21 416760 COMPRESSOR WIRING L1300 1
22 402284 SUCTION ACCUMULATOR 5" x 3/4" 1
23 439928 OUTLET PLASTIC RING OU8 2
26 436352 RAISING HANDLE OU10 2
31 416230 ELECTRONICS BOX DCI 4-5HP 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
34 416712 DCI 456 HP ODU Main Board (SPL) 1
37 416740 HP Switch 4.2/3.7 Mpa(g) 1
42 416550 EEV Assembly OU12 4-5HP DCI (SPL) 1
43 416602 COMPRESSOR INSULATION DCI 4-5HP Assembly (SPL) 1
45 416711 DRIVER 4-5HP DCI Assembly (SPL) 1
46 416715 PFC Chocks 4-5HP 2
47 416724 Terminal Block 6P 1
48 416726 Terminal block 2P DCI 1
49 416713 456 HP ODU Capacitor Board (SPL) 1
50 416730 EEV COIL VKV MOZS348E0 1
51 416751 OCT-THERMISTOR+CAP WTH CONNECT 1
52 416752 CTT-THERMISTOR+CAP WTH CONNECT 1
53 416762 Cable Driver Communication 1
54 416763 Cable IDU Communication 1
55 416764 CABLE INDOOR INPUT 1
56 416766 Cable Inrush Communication 1
57 416767 Cable Line filter-Driver 1
59 416769 Cable Terminals-Line filter 1
60 416770 Cable Terminal Ground 1
61 416774 CABLE CONTROLLER INPUT -OUT 1
62 416776 CABLE CAPACITOR DRIVER (EHK) 1
64 416906 *P.C SPACER RS-10 21
65 416910 CABLE HOLDER KWS-1 4
68 416714 456 HP ODU Filter Board (SPL) 1
69 416542 Tubing Assembly LIQUID VALVE O 1
70 416921 TERMINAL COVER DCI MITSUBISHI 1
71 438551 SUPPLY CORD CLAMP 20mm 2
72 762245 TERMINAL BLOCK N0.3 2/12
