Electra DNG 100 - OU12 6 HP DCI Outdoor Unit Spare Parts

15-18
EXPLODED VIEWS AND SPARE PARTS LISTS
SM OU12HP 2-E.2 GB
15.13.4 Outdoor Unit Spare Part List
No. Item Description Quantity
1 416246 UPPER COVER ASSY OU12 DCI 4-5H 1
2 417218 SIDE PANEL ASSY OU12 6HP DCI 1
3 436356 LARGE ELECTRICAL COVER OU/WMQ 1
4 416215 FRONT COVER OU12 DCI 4-5HP 1
4a 417219 FRONT PANEL ASSY OU12 6HP DCI 1
5 437091 OU SQUARE FAN GUARD 2
6 417200 NEW BASE ASSY OU12 6HP DCI 1
7 417201 Compressor Base Plate ASSY OU1 1
7a 417401 UPPER COIL GR HDR OU12 6HP DCI 1
7b 417400 LOWER COIL GR HDR OU12 6HP DCI 1
8 4529604 AXIAL FAN D493*143 2
9 416310 DC MOTOR 70W OU12 DCI 4-5HP 2
10 416218 SIDE GUARD OU12 DCI 4-5HP 1
11 436358 OU LEADING HANDLE 1
12 416222 MOTOR SUPPORT ASSEMBLY OU12-DC 1
14 417300 COMPRESSOR DA420A3F-20M 1
15 417528 Tubing Assembly OU12 6HP DCI 1
16 417518 Tubing Assembly OU12 6HP DCI 1
18 434549 SERVICE VALVE ASSY 3/4F 3 WAY R410A 1
19a 413712 THERMISTOR+CAP WITH CONNECTOR 1
19b 402741 THERMISTOR WTH CONNECTOR L1250 1
21 416760 COMPRESSOR WIRING L1300 1
22 402284 SUCTION ACCUMULATOR 5” x 3/4” 1
23 439928 OUTLET PLASTIC RING OU8 2
26 436352 RAISING HANDLE OU10 1
26 436352 RAISING HANDLE OU10 1
31 417230 CONTROLLER ASSEMBLY DCI 6HP 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
34 417713 DCI 6 HP ODU Main Board ASSY 1
37 416740 HP Switch 4.2/3.7 Mpa(g) 1
38 417742 LP Switch 0.15/0.2 Mpa(g) 1
42 417531 EEV Assembly OU12 6HP DCI 1
43 417603 COMPRESSOR INSULATION DCI 6HP 1
44 417711 HS DCI 6HP COATED 1
45 417712 DRIVER 6HP DCI Assembly 1
46 417715 PFC Chocks 6HP 2
47 416724 Terminal Block 6P 1
48 416726 Terminal block 2P DCI 1
49 417714 6 HP ODU Capacitor Board ASSY 1
50 416730 EEV COIL VKV-MOZS330E0(N-KV-13 1
51 416751 OCT-THERMISTOR+CAP WTH CONNECT 1
52 416752 CTT-THERMISTOR+CAP WTH CONNECT 1
53 417781 Cable Driver Communication 1
54 416763 Cable IDU Communication 1
55 416764 CABLE INDOOR INPUT 1
56 417782 CABLE ZERO CROSS 1
57 417784 CABLE LF-CHOCK 1
59 417785 Cable Terminals-Line filter 1
60 416770 Cable Terminal Ground 1
61 416774 CABLE CONTROLLER INPUT -OUT 1
62 417783 CABLE CAPS DRIVER 1
63 417914 P.C SPACER RS-14 4
64 416906 P.C SPACER RS-10 4
65 416910 CABLE HOLDER KWS-1 4
66 417787 CABLE DRIVER-CHOCK 1
67 417788 Cable Thermo Switch Shorted 1
68 417716 6 HP ODU Filter Board ASSY 1
69 416542 Tubing Assembly LIQUID VALVE O 1
71 438551 SUPPLY CORD CLAMP 20mm 2
72 417720 Terminal Block 4P 1
