Electra DNG 100 - Outdoor Unit Noise Measurement Scheme; Outdoor Unit Sound Pressure Spectra

7-3
SOUND LEVEL CHARACTERISTICS
SM OU12HP 2-E.2 GB
7.3 Outdoor Units
7.4 Sound Pressure Level Spectrum (
Measured as Figure 2)
OU12 4HP DCI Cooling OU12 4HP DCI Heating
OU12 5HP DCI Cooling OU12 5HP DCI Heating
Figure 2
1 m
1 m
