PRODUCT DATA SHEET
SM OU12HP 2-E.2 GB
2. PRODUCT DATA SHEET
2.1 DNG 100 DCI / OU12 4HP DCI
Model Indoor Unit DNG 100 DCI
Model Outdoor Unit OU12 4HP DCI
Installation Method DUCTED
Characteristics Units Cooling Heating
Capacity - Nominal (Minimum ~ Maximum)
(1)
Btu/hr 34100(10900÷39200) 38200(9200 ÷ 42650)
kW 10.0(3.8 ÷ 11.5) 11.2(2.6 ÷ 12.5)
Power input - Nominal (Minimum ~ Maximum)
(1)
kW 3.125(1.400 ÷ 4.400) 3.390(1.000 ÷ 4.450)
EER (Cooling) or COP(Heating)
(1)
W/W 3.2 3.3
Energy Efficiency Class “A” “C”
Power supply V/Ph/Hz 230 / 1 / 50
Rated current (Nominal) A 14.0 15.2
Starting current A 10
Circuit breaker rating A 25
INDOOR
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 890 / 800 / 670
Air flow
(2)
H/M/L m3/hr 2170 / 1880 / 1440
External static pressure Min-Max Pa 20 -100
Sound power level
(3)
H/M/L dB(A) 71 / 67 / 62
Sound pressure level
(4)
H/M/L dB(A) 52 / 49 / 47
Moisture removal (Nominal) l/hr 3.3
Condensate drain tube I.D mm 19
Dimensions WxHxD mm 854/297/816
Weight kg 33
Package dimensions WxHxD mm 1010/342/917
Packaged weight kg 38
Units per pallet units 6
Stacking height units 6
OUTDOOR
Refrigerant control Electronic Expansion Valve
Compressor type, model Scroll
Motor type DCBL Inverter
Fan type & quantity Axial 2 x 493 Ømm
Fan speeds H/L RPM 900 – 100 (Continuous)
Airflow Max m3/hr 5.200
Sound power level
(3)
Nom C/H dB(A) 67 / 69
Sound pressure level
(4)
Nom C/H dB(A) 56 / 57
Dimensions WxHxD mm 900 / 1255 / 340
Weight kg 110
Package dimensions WxHxD mm 985 / 1395 / 435
Packaged weight kg 120
Units per pallet Units 1
Stacking height units 1
Refrigerant type R410A
Refrigerant charge(standard connecting tubing
length)
Kg(m) 2.9 / 30
Additional charge per 1 meter g/m 38
Connections between
units
Liquid line In.(mm) 3/8" (9.52)
Suction line In.(mm) 5/8" (15.875)
Max.Tubing Length m. 70
Max.Height Difference m. 30
Operation control type LCD Remote control
Heating elements kW
—
Others
(1)
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1.0 meter distance from unit.
