EXPLODED VIEWS & SPARE PARTS LISTS
13-2 SM PXD 1-E.3 GB
13.2 Indoor Unit: PXD 9
No. Item Code Item Desc Quantity
13 221555 FILTER (SMALL) 2
25 234213 DISPLAY BOX PXD EHK: 906-041-02 1
22 263034 SWING MOTOR 1
7 293321 CENTRIFUGAL FAN (SMALL) 2
1 307979 BACK PANEL (SMALL) 1
14 307981 FRONT PANEL (SMALL) 1
30 311036 STORM METAL PANEL 1
6 323425 MOTOR SUPPORT LENGTH 99 1
19 370281 AIR OUTLET FRAME (SMALL) 1
18 371257 VERTICAL LOUVER CONNECTOR 10
21 372338 HORIZONTAL LOUVER FRONT (SMALL) 1
21 372339 HORIZONTAL LOUVER BACK (SMALL) 1
11 372341 FAN COVER (SMALL) 2
17 373244 RIGHT PANEL 1
12 373245 Side Plate / Left 1
4 373247 FAN FRAME(SMALL) 1
20 375209-16 DISPLAY PANEL ASSY.---ELECTRA 1
2 382334 BASE EPS (SMALL) 1
24 391508 CABLE DISPLAY 1
23 436665 STEP MOTOR 1
28 438082 Thermistor Indoor 1
27 438413 ROOM Sensor 1
9 4520158 MOTOR PXD 9-12-15 1
16 4520429 MOTOR WIRE ---PXD 1
9 4520929 Motor Assy. for PXD9-12-15 1
10 4521029 CLIP 2
29 4524613 STORM DST-8 10V7_W 916-355-13 ENG. VER. 1
3 452731900 Evap. assy. 1
8 452816100 Transformer 1
29 452837700 STORM-1 (PXD & K)916-355-18 1
None 452837700 STORM-1 (PXD & K)916-355-18 1
None 452837700R STORM-1 (PXD & K)916A355-18 1
5 455000600 Capacitor With Screw for fan motor 1
15 484001 AIR INLET ASSY (SMALL) 1
