EXPLODED VIEWS & SPARE PARTS LISTS
13-3SM PXD 1-E.3 GB
13.3 Indoor Unit: PXD 12
No. Item Code Item Desc Quantity
25 234213 DISPLAY BOX PXD EHK: 906-041-02 1
22 263034 SWING MOTOR 1
1 307979 BACK PANEL (SMALL) 1
14 307981 FRONT PANEL (SMALL) 1
6 323425 MOTOR SUPPORT LENGTH 99 1
19 370281 AIR OUTLET FRAME (SMALL) 1
21 372339 HORIZONTAL LOUVER BACK (SMALL) 1
17 373244 RIGHT PANEL 1
4 373247 FAN FRAME(SMALL) 1
9 4520929 Motor Assy. for PXD9-12-15 1
16 4520429 MOTOR WIRE ---PXD 1
9 4520158 MOTOR PXD 9-12-15 1
27 438413 ROOM Sensor 1
28 438082 Thermistor Indoor 1
23 436665 STEP MOTOR 1
24 391508 CABLE DISPLAY 1
2 382334 BASE EPS (SMALL) 1
20 375209-16 DISPLAY PANEL ASSY.---ELECTRA 1
15 484001 AIR INLET ASSY (SMALL) 1
5 455000600 Capacitor With Screw for fan motor 1
None 452837700R STORM-1 (PXD & K)916A355-18 1
None 452837700 STORM-1 (PXD & K)916-355-18 1
29 452837700 STORM-1 (PXD & K)916-355-18 1
3 452791200 Evap. assy. 1
29 4524613 STORM DST-8 10V7_W 916-355-13 ENG. VER. 1
8 4520933 Auto-transformer 1
12 373245 Side Plate / Left 1
21 372338 HORIZONTAL LOUVER FRONT (SMALL) 1
30 311036 STORM METAL PANEL 1
18 371257 VERTICAL LOUVER CONNECTOR 10
13 221555 FILTER (SMALL) 2
7 293321 CENTRIFUGAL FAN (SMALL) 2
10 4521029 CLIP 2
11 372341 FAN COVER (SMALL) 2
