EXPLODED VIEWS & SPARE PARTS LISTS
13-13SM PXD 1-E.3 GB
13.13 Outdoor Unit: ONG 9 RC
Item Code Item Desc Quantity
Drawing
Number Effective From Effective To
433218 Front Panel A 1 1 05-Mar-04 Active
433219 Front Panel A1 1 1 05-Mar-04 05-Mar-04
433221 Air Inlet Ring-420 1 2 05-Mar-04 Active
433223 Painting Insulation Plate 1 3 05-Mar-04 Active
4519251 Axial Fan OD=400 1 4 05-Mar-04 Active
4519250 Fan Motor YDK30-6V 1 5 05-Mar-04 Active
4527203 Motor Support 1 6 05-Mar-04 Active
4526747 Base Painting Assy. 1 7 05-Mar-04 Active
433217 Partition Plate 1 8 05-Mar-04 Active
455000503 Compressor Capacitor With Screw 1 9 05-Mar-04 Active
4519611 Electric Panel Painting Plate 1 10 05-Mar-04 Active
4524176 1/4 Liqiud Valve(R410A) 1 11 05-Mar-04 Active
4524177 3/8 Gas Valve(R410A) 1 12 05-Mar-04 Active
455000108 Double patch Capacitor for fan 1 13 05-Mar-04 Active
4514588 5 Poles terminal block 1 14 05-Mar-04 Active
204107 Cable clip Nylon 1 15 05-Mar-04 Active
236179 2 Poles terminal block 1 16 05-Mar-04 Active
4516637 Out sensor Black 1 17 05-Mar-04 Active
4527444 Restrictor (029) 1 18 05-Mar-04 11-Mar-04
4527127 Capillary Assy 1 19 05-Mar-04 Active
4527362 Charge tube TP2 6.35x0.8 1 20 05-Mar-04 Active
452799601 Compressor Jacket ONG3-9 1 21 05-Mar-04 Active
4514091 Grommet 1 23 05-Mar-04 Active
4510677 Nut With Flange M8 -D=24 1 24 05-Mar-04 Active
4527008 Wire assy 1 25 05-Mar-04 Active
4524230 Compressor assy. GK113PAG 1 26 05-Mar-04 Active
4516826 Rubber washer 1 27 05-Mar-04 Active
4516825 Cover Terminal 1 28 05-Mar-04 Active
4514089 Nut hex 1 29 05-Mar-04 Active
433229 cover valve 1 30 05-Mar-04 Active
433234 Clamp 1 31 05-Mar-04 Active
4519606 Right side panel (painting plate) 1 32 05-Mar-04 Active
4527135 4-Way Valve & Tube Assy 1 33 05-Mar-04 Active
433228 Back Side Net 1 34 05-Mar-04 Active
433216 Bridge 1 35 05-Mar-04 Active
4527155 condensor Soldering assy 1 36 05-Mar-04 Active
4519614 Painting Top Cover 1 37 05-Mar-04 Active
4519300 Nut M5 L 1 38 05-Mar-04 Active
433225 Handle 1 39 05-Mar-04 Active
4519607 Left Side Panel Painting Plate 1 40 05-Mar-04 Active
