EXPLODED VIEWS & SPARE PARTS LISTS
13-14 SM PXD 1-E.3 GB
13.14 Outdoor Unit: ONG 12 RC
Item Code Item Desc Quantity
Drawing
Number
Effective From Effective To
433218 Front Panel A 1 1 05-Mar-04 Active
433219 Front Panel A1 1 1 05-Mar-04 05-Mar-04
433221 Air Inlet Ring-420 1 2 05-Mar-04 Active
433223 Painting Insulation Plate 1 3 05-Mar-04 Active
4519251 Axial Fan OD=400 1 4 05-Mar-04 Active
4519692 Fan Motor (810rpm) 1 5 05-Mar-04 12-Mar-04
4526591 Motor YYK30Z-6 1 5 12-Mar-04 Active
4527203 Motor Support 1 6 05-Mar-04 Active
452772500 Base Plate Painting Assy. 1 7 05-Mar-04 12-Mar-04
4526747 Base Painting Assy. 1 7 12-Mar-04 Active
433217 Partition Plate 1 8 05-Mar-04 Active
455000504 Compressor Capacitor With Screw 1 9 05-Mar-04 12-Mar-04
455000502 Compressor Capacitor 35uF With Screw 1 9 12-Mar-04 Active
4519611 Electric Panel Painting Plate 1 10 05-Mar-04 Active
4524176 1/4 Liqiud Valve(R410A) 1 11 05-Mar-04 Active
4524177 3/8 Gas Valve(R410A) 1 12 05-Mar-04 Active
455000108 Double patch Capacitor for fan 1 13 05-Mar-04 12-Mar-04
455000000 single patch Capacitor for fan 1 13 12-Mar-04 Active
4514588 5 Poles terminal block 1 14 05-Mar-04 Active
204107 Cable clip Nylon 1 15 05-Mar-04 Active
236179 2 Poles terminal block 1 16 05-Mar-04 Active
4516637 Out sensor Black 1 17 05-Mar-04 Active
4526847 Valve-Capillary Assy 1 19 05-Mar-04 12-Mar-04
4526617 one way valve soldering 1 19 12-Mar-04 Active
4527362 Charge tube TP2 1 20 05-Mar-04 Active
4527058 Comp. Jacket 1 21 05-Mar-04 12-Mar-04
452799600 Compressor Jacket ONG3-7 1 21 12-Mar-04 Active
4516357 Rubber Cushion 1K15910311 3 23 05-Mar-04 12-Mar-04
4514091 Grommet 3 23 12-Mar-04 Active
4510677 Nut With Flange M8 -D=24 3 24 05-Mar-04 Active
4519987 Wire assy 1 25 05-Mar-04 12-Mar-04
4527375 Compressor Wire 1 25 12-Mar-04 Active
4526452 Comp. Assy GMCC PA145X2C-4FT 1 26 05-Mar-04 12-Mar-04
4526578 Compressor Assy. LG GK086P 1 26 12-Mar-04 Active
4526601 Compressor LG GK086P 1 26 12-Mar-04 12-Mar-04
4516359 Terminal Packing 1K14720130 1 27 05-Mar-04 12-Mar-04
4514088 Gasket 1 27 12-Mar-04 Active
4516358 Terminal Cover 1K14720012 1 28 05-Mar-04 12-Mar-04
4516824 Cover Terminal 1 28 12-Mar-04 Active
4516360 Terminal Nut 1K14300710 1 29 05-Mar-04 12-Mar-04
4514089 Nut hex 1 29 12-Mar-04 Active
433229 Valve Cover 1 30 05-Mar-04 Active
433234 Clamp 1 31 05-Mar-04 Active
4519606 Right side panel (painting plate) 1 32 05-Mar-04 Active
4526745 4-way Valve Welding Assy. 1 33 05-Mar-04 12-Mar-04
4526604 4-way Valve Welding Assy. 1 33 12-Mar-04 Active
4527308 PCB Support 1 34 11-Mar-04 Active
4526748 Low-Temp. Controller 1 35 11-Mar-04 Active
433228 Back Side Net 1 36 05-Mar-04 Active
433216 Bridge 1 37 05-Mar-04 Active
4526804 condensor Soldering assy 1 38 05-Mar-04 12-Mar-04
4526605 condensor Soldering assy 1 38 12-Mar-04 Active
4519614 Painting Top Cover 1 39 05-Mar-04 Active
4519300 Nut M5 L 1 40 05-Mar-04 Active
433225 Handle 1 41 05-Mar-04 Active
4519607 Left Side Panel Painting Plate 1 42 05-Mar-04 Active
4516114 2-W Valve coil 1 43 11-Mar-04
A
ctive
