OPTIONAL ACCESSORIES
14-9SM PXD 1-E.3 GB
MODELS SXSP 9 - 12 - 15 - 18 - 24 - 30 - Connect the wires with 6.35 connectors directly to the control board
as shown
Black wire to 7 Violet wire to 7
SXSP 9 - 12 - 15 - 18 - 24 - 30
Blue wire to 8
