Electra WNG 7 - System Description

1.Air intake grille
2.Air filter
3.Supply air flap
4.Air outlet
5.Unit's indicators
6.Horizontal Air flow
Deflecting louvers
7.On unit's controls
8.Power cord
9.Outdoor unit air intake
10.Power cable
11.control wire
12.Air-fresh controls wire
(optional)
13.Liquid line
14.Suction line
15.Air-fresh hose (optional)
16.Drain hose
17.Outdoor unit air outlet
18.Remote controls holder
19.Remote control
20.lonizer (optional)
21.Air purifying filter
22.Electrostatic filter (optional)
SYSTEM DESCRIPTION
