Mounting
- Slide the fork inside the clamp one by one
- Adjust the position on the fork with the distance of 8mm
- Screw the M6 screws of the clamp at 11 Nm
- Approach the upper and lower fork crown bolts loosely,
- Using a torque spanner, tighten the upper and lower fork
crown bolts to 11 Nm.
- Refit the front brake caliper/offset bracket
assembly to the left fork arm. Use a 5mm
Allen key to tighten to 10N.m. Be sure to
replace the washers.
- After tightening the tees,
tighten the wheel axle to
40Nm
Compress the fork gently (approx. 3 to 4
cm) and repeat the operation 2 to 3
times to centre the wheel axle,
Tighten the wheel axle flange via the 2
screws to 6Nm.
- Fit the mudguard bracket, making sure that it does not have to be
forced into place. Tighten to 10 Nm
Take care to test the performances of the front brake before
riding, it’s possible that during mounting the front caliper piston
should be not ready to brake directly, make some braking with the
handlebar lever.
