Setting Series
Hydraulic setting
When adjusting it is best to always close the hydraulic by turning the
screw completely and go back to the desired setting. The factory
setting is 16.
Setting Spring
The spring setting is adjusted with a 6mm Allen key. When adjusting
it is best to always screw completely and then unscrew the desired
number of turns, 11 turns allows this adjustment. The factory setting
is 6 turns.
11.2 Clean the fork
It’s necessary to clean the fork after each use, to avoid any damaged
seal.
- Stop the motorcycle ( 9.5).
- Put the motorcycle on a stand (wheels in air) ( 12.1).
- Lubricate the dust seal protectors,
- Clean the fork tube with clean cloth and install grease.
- Remove the excess of grease.
Absolut forbidden, all aggressive products.
Do not use high pressure water jet directly on the seal.
11.3 Chain tension adjustment
- Bike on a stand
- Chain tension should be at 25mm for the swingarm and
the upper face of the chain tensioner rubber
