ELECTRIC MOTION Epure Lite 2021 - Removing and Refitting the Front Mudguard; Dismantling and Reassembling the Handlebars

USER MANUAL - 2021
43
11.5 Removing and refitting the front mudguard
Disassembly
- Stop the vehicle (9.5).
- Raise the motorbike on a stand.
- Remove the fender fixing screws with a 3mm Allen key.
- Remove the front mudguard.
Reassembly
Perform all disassembly actions in reverse order for reassembly,
11.6 Dismantling and reassembling the handlebars
Disassembly
- Stop the vehicle (9.5).
- Raise the motorbike on a stand (12.1).
- Remove the upper bridge bolts using an 8mm Allen key.
- Take out the handlebars
