OPERATION AND SETTINGS
This portable air conditioner boasts four functions: cooling (spot cooling or vented), dehumidifying,
humidifying, air cleaning (with optional HEPA filters) / fan and humidifying.
The fan has three speeds: high, medium and low
Temperature range settings are: 17-30
0
C
The unit will also display operating function, temperature, humidity, fault diagnostic and protective
functions on the LCD screen.
Control panel
(1)
Power ON / OFF
(2)
Function selection
(3)
Humidity / Temp +
(4)
Humidity / Temp -
(5)
LCD Display
(6)
Fan Speed
(7)
24 hrs timer
(8)
Sleep mode
(9)
Swing function
Air Purifier mode
Temperature / Humidity / Hours
Sleep mode on
Temperature
Timer on
Humidity
Humidifier mode
Time
Swinging on
Fan speed icon
Error Alarm
Auto mode
Air Conditioner mode
Fan speed
Dehumidifier mode
Child Lock
