Serial Link
(recognized +
transmitted)
MIDI-Byte Ddescription
F0 (hex)
00,00
76
0n
26
01
DATA
CHECKS
F7
System Exclusive
Extended ID (two bytes)
Electro-Voice ID: No 118
n = MIDI Channel 0 - 15 (7F = All Channels)
Dx 38 ID: No 38
Function ID: Serial Link / Parser
ASCII Code Line for Command Parser (up to 120
Byte)
Checksum for DATA (7 Bit, 2’s Complement)
End of SysEx Message
Further details concerning the Command Parser ASCII Code are shown in the following tables.
Device Commands
UNIT-ID Tree Value Unit
/ID1/
COMMAND/
STORE 1 ... 30
LOAD 1 ... 80
DUMP 0 ... 30
DEVICE ?
Com Port Configuration
Tree Value Unit
COMCONF
LINEFEED ON/OFF
PROMPT ON/OFF
ECHO ON/OFF
MIDI
10-3
