PA Series Product Specifications:
PA2450L PA4150L PA2400T PA2250T PA1250T
Number of Channels 2 4 2 2 1
Load Impedance 8ohm 4ohm 8ohm 4ohm 8ohm 4ohm 100V 70V 8ohm 4ohm 100V 70V 100V 70V
Rated output power (*rated load)
THD<1%, 1kHz
220W 450W 100W 160W 215W 430W 430W 430W 135W 270W 270W 270W 270W 270W
Rated output power (*rated load)
THD<0.2%, 20Hz ... 20kHz
200W 400W 75W 150W 200W 400W 400W 400W 125W 250W 250W 250W 250W 250W
Slew rate at 1kHz 28V/µs 16V/µs 25V/µs 65V/µs 46V/µs 18V/µs 61V/µs 41V/µs 61V/µs 41V/µs
Frequency response -1dB, ref. 1kHz <10Hz -40kHz <10Hz -40kHz 65Hz -40kHz 65Hz – 20kHz 65Hz – 40kHz 65Hz – 20kHz 65Hz – 20kHz
Damping factor at 100Hz / 1kHz,
4ohm
>250 >250 >250 N/A >250 N/A N/A
Power bandwith THD=1%, ref. 1kHz,
half power
<10Hz ... >50kHz <10Hz ... >50kHz 45Hz … >20kHz 45Hz … >20kHz 45Hz … >20kHz
Input impedance 20Hz ... 20kHz,
balanced
>20kohm >20kohm >20kohm >20kohm >20kohm
Signal to noise ratio A-weighted 104dB 100dB 103dB 103dB 103dB
Input sensitivity at rated output
power or voltage, 1kHz
0dBu (775mV) 0dBu (775mV) 0dBu (775mV) 0dBu (775mV) 0dBu (775mV)
THD at rated output power
MBW=80kHz, 1kHz
<0.1%
IMD-SMPTE 60Hz, 7kHz <0.1%
DIM30 3.15kHz, 15kHz <0.1%
Crosstalk ref. 1kHz, at 10% rated
output power
<-75dB
Power requirements 120V or 230 V, 50Hz -60Hz
Protection Audio limiters, high temperature, peak current limiters, turn-on delay
Cooling Front-to-rear
Dimensions W x H x D, In. (mm) 19.0 (483) x 3.5 (88) x 16.0 (406)
Weight 36.34lbs (16.5kg) 39.65lbs (18kg) 57.27lbs (26kg) 51.76lbs (23.5kg) 36.34lbs (16.5kg)
